Known Problems:

• Check Engine light and AT lights are on
• Vehicle stays in 3rd gear only (safe mode)
• Hard kick on drive and reverse
• Hard shifting
• Codes U0101, U0100 (Lost communication with TCM)
• Code P0753 (Shift Solenoid 'A' Malfunction)
• Code P0758 (Shift Solenoid 'B' Malfunction)
• Code P0763 (Shift Solenoid 'C' Malfunction)

Compatible Part Numbers Include:

{2.0L Engine}

• LFJE 18 9E1B, LFJE 18 9E1C, LFJE 18 9E1D
• LFJE 18 9E1H, LFJE 18 9E1A, LFJE 18 9E1B
• LFJE 18 9E1C, LFJE 18 9E1D, LFJE 18 9E1H
• LFJE 18 9E1E, LFJJ 18 9E1A, LFJJ 18 9E1B

{2.5L Engine}

• L5F8 18 9E1A, L5F8 18 9E1B, L5F8 18 9E1C
• L5F8 18 9E1C

It is your mechanic's responsibility to pinpoint the problem to the TCM. Solenoids and wiring harness must be tested for possible failure or short. Faulty transmission control modules will ALWAYS illuminate AT light and/or check engine light and produce trouble codes. If you or someone else tried to repair your transmission control module, we can evaluate and possibly repair it, but only in the case that no additional damage was created. Please note, not all modules are repairable.
